Reusable Endocavity Needle Guide
راهنمای سوزن حفره ای چندبار مصرف
/
توضیحات
Reusable Endocavity Needle Guide
For use with Samsung Medison BCC4-9 transducers (Product Number:657-028)
The contoured design of this stainless steel needle guide provides a low profile fit to the transducer, allowing users to perform precision biopsy procedures with ease and accuracy. The needle guide is secured to the transducer by repositioning and tightening the thumbscrew into the closed position. To reuse the needle guide, follow standard cleaning, soaking and sterilization procedures as specified in your system manual. This reusable guide accepts 16-18GA instruments and offers a 3.8° angle. When using this guide, a 14cm (5.5”) needle is recommended to reach target area.
Features & Benefits
- Accurate needle path with on-screen guidelines offer physicians real-time visualization ensuring patient safety throughout the procedure.
- Reduces technique variability providing a shorter learning curve and reduced procedure time.
- Endocavity guide features a funnel for instrument insertion and will accept a full range of sizes including 16-18GA.
- Needle guide does not compromise cover integrity during probe set-up.
Description
Non-sterile endocavity needle guide, cleaning brush 22.9cm (9″) (5) (Ref# 476-074)
